LINEAPORTA

• Minimal narrow edge visible surface width up to 18mm;
• Adopting an invisible track system with two double stainless steel rollers on each side, each opening fan moves on at least eight rollers;
• Special design scheme for freely adjustable hidden drainage;
• The stylish design of the handle provides maximum safety;
• Can achieve rapid assembly, installation, and after-sales maintenance;
• Maximum fan height: 4.2 meters (depending on visible surface width, frame width, and wind load);
• Maximum fan width: 2.8 meters (depending on visible surface width, frame width, and wind load);
• Maximum fan load: 400-800kg (depending on the number of wheels);
• Maximum sliding fan area: 12sqm;
• Maximum fixed fan area: 18 sqm;
• Standard glass configuration: 8G tempered+24A+8G tempered;
• Conventional opening method: manual opening (non-standard requires special customization)
• Standard profile color: porcelain swimming black/porcelain swimming antique copper;
• Hidden security components, reaching the European RC2 security level
